Finding the IP address of an Allen Bradley Programmable Logic Controller (PLC) is a crucial task for industrial automation professionals. It enables seamless communication between a PLC and other devices on an Ethernet/IP network. In this article, you will discover effective methods on how to locate the IP address of an Allen Bradley PLC.

Whether you're troubleshooting connectivity issues, setting up new equipment or modifying an existing system, having the knowledge to locate a PLC's IP address can significantly improve efficiency in industrial automation systems. Delve into this guide to gain a deeper understanding of the necessary steps and tools required to locate the vital information you need for your Allen Bradley PLC system.

Understanding Allen Bradley PLCs

Allen Bradley, a product line of Rockwell Automation, has been a major player in the automation industry since the invention of the original Programmable Logic Controller (PLC) in the 1970s. With a flexible and scalable approach, Allen Bradley's programmable automation controllers (PACs) meet various application requirements, from simple to complex systems (Rockwell Automation) .

Allen Bradley PLCs are designed to handle different industry needs, such as process control, safety, and motion applications. The PLC's primary function is to execute a set of instructions by receiving input signals, processing them, and sending output signals to control other devices. Some popular series of Allen-Bradley PLCs include Micro800, CompactLogix, ControlLogix, and SLC 500.

When working with Allen Bradley PLCs, it is essential to know their IP addresses for configuring and implementing an Ethernet-based communication system. The IP address enables communication between the PLC and other devices, such as Human-Machine Interfaces (HMIs), remote I/O modules, and other controllers (PLCS.net) .

Each PLC has its specific software for programming and monitoring, such as RSLogix 5000 for ControlLogix and CompactLogix controllers, and RSLogix 500 for SLC 500 and MicroLogix controllers. Additionally, tools like RSLinx are utilized for communication setup and management, which helps maintain the EtherNet/IP connections among various devices (PDF Supply) .

Gathering Necessary Tools and Software

Before you begin the process of finding the IP address of your Allen Bradley PLC, it's essential to gather the necessary tools and software. This preparation ensures a smooth workflow and reduces the chance of running into difficulties during the process.

First, you'll need a computer with a compatible version of RSLogix 5000 or Studio 5000 software installed. This powerful software enables you to communicate with and configure Allen Bradley PLCs, including setting and discovering IP addresses. If you don't already have this software, you can download it from the Rockwell Automation website.

Next, gather the necessary hardware to connect your computer to the PLC. In many cases, this involves using an EtherNet/IP network cable. However, some models may require a serial or USB connection. Ensure that you have the appropriate cables and adapters for your specific Allen Bradley PLC.

With the software and hardware ready, follow these steps to configure your computer's network settings:

1. Identify the subnet used by your PLC to prevent IP address conflicts.
2. Configure your computer's network card settings to match the PLC's subnet, based on the PLC's documentation.

Now you're all set with the necessary tools and software, and your computer is configured properly to communicate with the Allen Bradley PLC.

Step by Step Process to Find IP Address

Before you begin the process of finding the IP address for your Allen Bradley PLC, ensure your PC and PLC are properly connected using an Ethernet cable. You can typically find the Ethernet port on the PLC's front.

Firstly, download and install the Rockwell Automation BootP DHCP software on your computer. This software will enable you to discover and assign IP addresses to your PLC without any hassle. Follow these steps once the software is installed:

1. Launch the Rockwell Automation BootP DHCP software on your computer. You can find it by accessing Start Menu > Rockwell Software Packages > BOOTP/DHCP.
2. Power on your Allen Bradley PLC. After a few seconds, your PLC will start requesting an IP address, which will be displayed in the BootP DHCP Server software.
3. Right-click on the device's MAC address in the software and choose "Add to Relation List."
4. Now, select the added device in the relation list and click on the "Disable BOOTP" button. This will allow you to assign a static IP address to the PLC.
5. Enter the desired IP address, subnet mask, and gateway for the PLC.

At this point, it is recommended to power cycle your PLC to ensure the IP address has been saved. To verify the IP address, you can use free software tools like Advanced IP Scanner or use your computer's built-in command prompt.

Keep in mind that your PC's IP address should be in the same subnet as the PLC for proper communication. Once you have successfully assigned and verified the IP address, you can proceed to set up the communication parameters in the Rockwell Studio 5000 software or any other program you're using to interface with the PLC.

Troubleshooting Common Issues

Finding the IP address of an Allen Bradley PLC can sometimes be met with challenges. One way to troubleshoot common issues is by using the RSLinx software paired with the Ethernet/IP communications driver (Automation Ready Panels). This combination allows you to access and view PLC information, including the IP address.

Some frequent issues and their solutions include:

• PLC not detected: If the PLC isn't showing up in RSLinx, ensure it is connected with an appropriate Ethernet cable, the software configuration is correct, and check the network settings on your computer.
• Incorrect IP configuration: If you are unable to communicate with the PLC, confirm the IP address and subnet mask of the PLC and your computer are compatible (Ethernet Troubleshooting YouTube Video). Adjust network settings if needed.
• Changing IP address: If you need to set a different IP address for a new Allen Bradley PLC, try using the BOOTP/DHCP tool (SolisPLC tutorial). Follow the provided steps to properly assign the desired IP address.

Remember to consult the manufacturer's documentation or reach out to their support team for assistance when encountering issues specific to their products (Rockwell Automation documentation). With careful troubleshooting and attention to detail, you'll be able to resolve most Allen Bradley PLC IP address issues efficiently.

Conclusion

In this article, we have explored the process of finding the IP address of an Allen Bradley PLC. Identifying the IP address is crucial for connecting to and configuring the PLC for various tasks. There are several techniques available for discovering the IP address, including the BOOTP/DHCP method as explained in Solis PLC.

Taking advantage of network scanning tools and software is another approach to uncover the critical information for PLC communication. Emphasis should be placed on accuracy and security when employing these methods, as they are vital for maintaining the integrity of the PLC network and the devices connected to it.

To summarize:

• Locate the IP address of the Allen Bradley PLC with the appropriate tools and techniques, such as BOOTP/DHCP.
• Utilize network scanning tools to discover device information and make the process easier.
• Maintain accuracy and security while handling PLC networking and configuration.

By following these steps, you can effectively establish communication with your Allen Bradley PLC and ensure that the systems connected to it perform optimally.
