How To Reset Allen Bradley Safety Relay

Resetting an Allen Bradley safety relay can be a simple process but it is important to ensure that you are following proper procedures to avoid any potential hazards. In this blog post we will go over the steps you need to take to reset your safety relay.

Before you begin, its important to make sure that the power to the relay is turned off. This can typically be done by switching off the main power switch for the machine or equipment that the relay is controlling.

Once the power is off, you'll need to locate the reset button on the safety relay. This button is typically located on the front of the relay and may be labeled as "Reset" or "RST".

Once you've located the reset button, press and release it. This should reset the relay and clear any fault conditions that may have been present.

It's important to note that some safety relays may require additional steps to reset, such as holding the reset button down for a certain amount of time or cycling the power to the relay. Be sure to consult the instruction manual for your specific safety relay to ensure that you're following the correct reset procedure.

Once the safety relay has been reset you can turn the power back on to the machine or equipment. Its important to perform a test run of the equipment to ensure that it's functioning properly before putting it back into service.

In summary resetting an Allen Bradley safety relay is a relatively simple process, but its important to follow proper procedures to avoid any potential hazards. Be sure to consult the instruction manual for your specific safety relay and perform a test run of the equipment before putting it back into service.
